Marconi Instruments 2390A 9kHz-22GHz Spectrum Analyzer This item is a Marconi Instruments 2390A 9 kHz to 22 GHz Spectrum Analyzer with Tracking Generator Option 002. The 2390A is a microprocessor controlled, digitally synthesized spectrum analyzer. It utilizes a numeric keypad, dedicated function keys, multitask Soft Function Keys, and a high resolution LCD to display, enter and edit functions and data. Testing is done manually using external front panel controls or remotely through the RS-232 or IEEE0488 external interface. Microprocessor controlled memory allows storage and recall of parameters for each of the major testing modes as well as storage and recall traces for signal comparison. It operates as a Spectrum Analyzer, Frequency Counter, Digital Oscilloscope, or AM/FM Receiver. This Spectrum Analyzer features: * +30 to -135 dBm measurement range * Tuning Range of 0 Hz to 22 GHz * Readout Accuracy of +- (3% of Frequency Span Width + Frequency Standard Accuracy + 50% of RBW) * Frequency Counter Resolution of 1 Hz, 10 Hz, 100 Hz, 1 kHz * Frequency Counter Accuracy of +- Frequency Standard Accuracy + Counter Resolution * Sweep Time (Frequency Span >200 Hz/Div): 1 ms to 10 s/Div in 1-2-5 sequence * Sweep Time (Frequency Span = 0): 200 ns/Div to 10 s/Div in 1-2-5 sequence * Sweep Rate Accuracy of +- 1% of Full Scale, >= 2us/Div * 16 cm (6.4 in) color VGA TFT LCD Display that shows up to 4 traces on the screen for comparison of live or previously stored signals. * Digital Resolution of 640 pixels x 480 pixels * Single and Dual markers on the display to provide easy measurement of any portion of the displayed signal. * Time Domain (Scope) Frequency Range of dc to >=5 MHz (-3 dB) at <= 2us/Div Sweep Time * Frequency Domain Amplitude Gain of 0 to 20 dB in 0.1 dB steps and Attenuation of 0 to 60 dB in 20 dB steps * 3.5 mm phone jack connector output * IEEE-488 GPIB Interface Connector that conforms to IEEE-Standard 488-1987 * Half Duplex RS-232 Interface Connector * Tracking Generator Frequency Range of 100 kHz to 2.9 GHz * Tracking Generator Output level of 0 to -70 dBm in 1 dB steps and Attenuator Accuracy of +- 1 dB or 0.05 dB/dB * Compatablility with Epson 24, Epson 9, Thinkjet, or Laserjet printers For product questions or details, please email lillian.brennan@modularparts.com To add Ridge Equipment to your favorite stores simply click this link, or you can click here to visit our store, and then click the "Add to My Favorite Stores" link in the upper right hand corner. You must check the box underneath the heading "Ridge Equipment Company" Newsletter in order to receive special offer emails from us. Money Orders, and I-escrow are also welcome. (please look at our rules and privacy policy) |
