"#2500 12" Lathe Instructions Manual" This is a reproduction, not a photocopy, of an original Logan 12" Lathe #2500 as well as the Turret and Screw cutting models Instructions Manual. This manual contains information on setup, lubrication, maintenance, adjustments, and controls of this lathe. Part Location Pictures...................................1 Setting Up the Lathe.....................................2 Variable Speed Drive Maintenance...............3 Headstock Maintenance...............................3 Back Gear Maintenance...............................4 Tailstock Operations.....................................5 Apron Operations.........................................6 Friction Clutch Operations............................6 Saddle Operations........................................7 Compound Rest Assembly............................7 Power Feed Operations................................8 Turret Assembly............................................9 Lubrication Diagram....................................10 Lubrication Instructions................................11 I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench. Be sure to add my store to your favorites list! I am adding new manuals all the time. PLEASE READ the return policy and COMPLETE description of the manual. Because of the nature of this product, I do not accept any returns or exchanges under any circumstances. If you have any questions, email me or send me a picture first. I (please look at our rules and privacy policy) |
