Up-front bevel lock lever and range selector knob - Easily-accessed controls for quick Arbor mounted laser tracking - Provides accurate laser lines for precision cutting. Multi-position main handle - Easily locks into any of four positions for optimum comfort and control. Large 25-1/2" base with built-in cast sliding extensions for 40" total length. Tall 4-1/2" speed track sliding fences - For Built-in length stop - For repetitive Easily readable bevel and miter scales - For easy setting of accurate bevel and miter angles. Exclusive wedge-and-slot miter detent system - Consistent and precise miter angles Miter detent override - For fast adjustment bevel detents for quick, accurate crown cuts. Dual sliding rail design - For superior accuracy. Electric brake - For quick, repetitive cuts. Stops Rating ................................................................. 120V AC Amperage ..................................................................... 15 No Load RPM .......................................................... 3,800 Max. Motor HP ................................................................ 3 Blade Diameter (in.) .................................................... 12" Arbor Size ..................................................................... 1" Height (in.) ................................................................... 20" Weight (lbs.) ................................................................. 59 Length (in.) ...................................................................40" Bevel Angle Range .......................... 47 Bevel Detents ......................33.9,45 Miter Angle Range ............................. Miter Detents ................................... 0,15,22.5,31.6,45 Crown Molding - Angled Against Fence ................ 6" Max "spring" angle from wall) using 31.6 Base Molding - Against Fence ........................ 4-1/4" Max Base Molding - Laying Flat ......................................... 12" Miter/Bevel (Max Height x Width) 0 degree/0 degree-4-1/2" x 12" (4" x 12" Nominal) 0 degree/45 degree-2-3/4" x 12" (2" x 12" Nominal) 45 degree/ 0 degree- 4" x 8-1/2" (4" x 8" Nominal) 45 degree/45 degree Left -2-3/4" x 8-1/2" (2" x 8" Nominal) Tool-free Versicle Work Clamp. (please look at our rules and privacy policy) |
