Liberty Machinery Company-You are looking at a 21.65" Okuma & Howa, No. ACT 2SP-V5, 24" Maximum Turn Length, (2) 15" Chucks, Fanuc O-TT-Serial No. 2001 -SPECIFICATION: Distance Between Centers 31.69" (805 mm) Turning Diameter - Maximum 21.65" (550 mm) Turning Length - Maximum 24.01" (610 mm) Spindle Center Height from Floor 41.73" (1060 mm) Headstock - Spindle Nose JIS A2-8 - Spindle Diameter 6.29" (160 mm) - Hole Taper 4.52", 1/20 (115) - Hole through Spindle Diameter 4.33" (110 mm) - Spindle Support By Roller Bearing at Two Points Spindle Drive - Number of Spindle Speed Stepless Spindle Speed 20 - 2000 RPM/Min. Spindle Speed Command Method Speed of Revolution Direct Command Constant Surface Speed Cntrl Avail Spindle Speed Override at 10% Steps 50 - 200% Type of Turret V12 + V12 (Shorter Rev. Indexing) Turret Maximum Number of Tools 12 + 12 Piece Turret Standard Tool JIS No. 4 (Sq. 25 mm) Turet Boring Bar Diameter 50" (40 mm) Axis Feed Travel - X-Axis 12.59" (320 mm) Axis Feed Rapid Traverse Rate - X-Axis 472 IPM (12 m/Min.) Axis Feed Cutting Feedrate 0.00001 - 19.68"/Rev. Axis Feed Cutting Feed Override 0 - 200% at 10% Steps Floor Space Required Width x Depth 137.99" x 113.77" (3505 x 2890 mm) Overall Machine Height 129.92" (3300 mm) Approximate Weight 41,800 Lbs. (19,000 kgf) (2) Chip Conveyors Disposed to the Rear of the Machine High-Power Spindle Specifications - 20 - 2000 RPM (AC 22/30 kW) 15" 3-Jaw Serreted Type Howa H01MA15 (A2-8 Direct) Hydraulic Chuck (Dust - Waterproof)- (please look at our rules and privacy policy) |
