HP 8690B Sweep Oscillator w/Opt. 8693A-H40 *Tested* All functions tested, all good. The familiar 8690 BWO sweeper family offers exceptional value in performance, operation and versitility. With the ability to accept both BWO and solid state plug-ins, the 8690 mainframe allows BWO coverage where necessary, and more reliable, high performance solid state coverage at lower frequencies. The 8690B Sweep Generator Mainframe provides start-stop sweep, marker sweep, and CW operation functions. Sweep modes are continuously adjustable in four decade ranges, 0.01 to 100 seconds. Two frequency markers independently adjustable over entire frequency range of 0.001 to 40 GHz (depending on the plug-in used). Typical accuracy is 1% of full scale. Includes plugin 8693A-H40 The 8693A RF Plug-In is a BWO module designed for use with the 8690 Sweep Oscillator Mainframe. Freguency Range: 4.0 to 8.0GHz, ?1% Power Control: GRID Maximum Leveled Power: >30 mW Frequency Stability: <80MHz Residual FM peak: <50kHz Type N connector. HP/Agilent 8693A RF/Oscillator Plug-in. 4 to 8 GHz. For HP 8690. RF Plug-In is a BWO Module Designed for Use With the HP 8690 Sweep Oscillator Mainframe. Freguency Range: 4.0 to 8.0GHz, 1% Power Control: GRID Maximum Leveled Power: > 30 mW Frequency St Local Pick up is also available at our office in Clayton South VIC 3169 with 24 Hrs Prior Notice. Building Trust in Transactons (tm) If you have any questions please contact Lily or Phone (switch) +613 9558 0004 Ext : 138 Office Hours are 9.00AM - 5.00PM (please look at our rules and privacy policy) |
