Original Service & Operation Manuals (with Option 5 insert) Original Tektronix manuals in excellent condition. The service manual includes the option 5 modification insert (TV Sync Generator). The sections in the service manual are seperated by tabs and contains schematics, diagrams and a section on maintenance. Well over 400+ crisp pages, binded. - Section 2: Operating Instructions - Section 3: Circuit Description - Section 6: Electrical Parts List - Section 7: Diagrams & Circuit Board Illustrations - Section 8: Mechancal Parts List & Illustrations PHOTOS BELOW ARE OF THE ACTUAL MANUALS (please look at our rules and privacy policy) |
