Tektronix 50M30 Service and Operating Manual plus Reference Guide in both Very High and in Standard Resolution PDFs on CD For a sample of the complete "standard" res PDF of the included reference guide, click HERE. (No need to "email for samples," so no need to worry about getting sold to a SPAM list!) (Please read FAQ or "About Me" Page) SCAN PARAMETERS (Very High Res PDF): Text with photos: 600dpi grayscale (contrast adjusted) Text with Drawings: 600dpi black and white Schematics: 600dpi black and white Schematics and PCB Photos w/Color (if any): 600dpi 256 color Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. Unfortunately, in order to delay the inevitable plagiarism of these by "marketing' and "leeching" scanned manual CD distributors, we were forced to lock them against changes. However, they are not locked against printing high resolution pages. The majority of scanned manual vendors distributing their own products as opposed to internet downloads or plagiarized material do lock the PDFs against changes, we're just the only folks who tell you about it up front. "AND IF THAT'S NOT ENOUGH FOR YOU": As "bonus" material, includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF as well as a useful text-searchable scan of the 1990 Tektronix Catalog, featuring almost 3,000 Tektronix Products, all at no additional charge! More bonus items on the CD! Here's a description of additional bonus items now included: The document tm5x1977_sm.pdf is a 1977 Tektronix sales publication with considerable useful information on elements of the TM500 series. The document TM500_Supplies_sm.pdf contains information from Tektronix regarding suggested power supply circuits for use in the TM500 series blank module kit. The document tm5xrib_sm.pdf is the entire Tektronix "Rear Interface Data Book" that details pinouts on the rear of TM500 series modules and interconnections between them in the power modules. Last but not least, you get text-searchable scans of the service/operating manuals for the TM501, TM503, TM504, TM506, TM515 and TM5006 Power Modules. (please look at our rules and privacy policy) |
