The HP8684B has a frequency range of 5.4 - 12.5 GHz. -130 to +10 dBm (overrange +15dBm) RF Output. Portable cavity-tuned source with high performance modulation. Internal pulse modulation source. Wide FM deviation for satellite video and more. Frequency Specifications: * Range: 5.4 - 12.5 GHz * Resolution: 10 MHz Spectral Purity: Harmonics: < -25dBc Output Specifications * Range (leveled into 50 ohms): +10 to -130 dBm * Resolution: 0.1 dB Amplitude Modulation * Depth (1 kHz rate): 0 - 70% * Rates (3 dB BW at 40% depth): dc to 10 kHz (dc coupled); 50 Hz to 10 kHz (ac coupled) Frequency Modulation * Peak deviation: ± 5 MHz * Rates (3 dB BW): dc to 10 MHz, 100 Hz to 10 MHz (ac coupled) Pulse Modulation - Internal Pulse Generator * Rate: 10 Hz to 1 MHz * Width: 50 ns to 100 ms . Reasonable offers are well come! REASONABLE ONES! My phone # is (***)-235-5613. This is my website for more equipment you may need: http://aaaequipmentresources.com/index.html (please look at our rules and privacy policy) |
