Tektronix 2445 Service Manual and 2445/2465 Option 10 (GPIB) Service Manual Why settle for just one resolution? You get them both! Also includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF at no additional charge! Have any questions? Check our FAQ or "About Me", please. These manuals cover maintenance and servicing of the Tektronix 2445 Oscilloscope, including the full manual for the GPIB Option (Option 10). The Opt 10 Manual is listed as a service manual, but contains all operating information you need to use the option along with plenty of general information on GPIB as well as the usual specifications, theory of operation, performance check and cal procedures (the real thing.. no free military or OEM website downloads snuck in.. "We are not our competitor"), maintenance info including troubleshooting & error code flowcharts, full schematics & PCB drawings, parts lists, plus five appendices of GPIB information. They are scanned from the original manufacturer's manuals. The scans came out well, and all information available in the original manuals is available here. Two PDFs of each manual are provided, in two resolutions. One is: Text with Drawings at 600dpi black and white or grayscale (content-dependent) Schematics at 600dpi black and white or grayscale (content-dependent) Text with photos at 600dpi (minimum) grayscale with contrast adjusted Schematics, overlays with color notes (if any) at 600dpi 256 colors (minimum) The other PDFs are done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. Both versions are well bookmarked. The smaller, faster PDFs are also TEXT-SEARCHABLE. The material is reproduced with permission, Courtesy of Tektronix, Inc. (please look at our rules and privacy policy) |
