The module can be interface by connect the common pin to GND and pin a-dp to 8-bit I/O pins of any microcontroller. A segment can be light up by sending logic HIGH to the display. It is easier to decode if user interface I/O pin of microcontroller as same as 7-segment’s pin arrangement. PCB size is 1.20†x 0.90†· Onboard current limited resistors For more information please see: MR-MINI-7SEG-CC User Manual “This is sold fully assembled and tested†For more exciting products please visit WWW.MICRORESEARCH.US (please look at our rules and privacy policy) |
