* AC Voltage: 4V - 40V - 400 - 600V * DC Voltage: 4V - 40V - 400V - 600V * AC current: 0 - 400A - 600A - 1000A * DC current: 0 - 400A - 600A - 1000A * Resistance: 0 - 400 - 4K - 40K - 400K - 4M - 40M Ohms * Frequency: 40Hz - 600Hz - 6KHz - 60KHz - 100KHz, 1 V - 10V RMS, 40Hz - 100KHz * Frequency measurement for clamp: 40 Hz - 400 Hz * Data hold, Back light on LCD and Flash light on the top * Accuracy : 2.5% of reading * Max common mode voltage: 600V AC RMS * Reading hold: H on the display * Power supply: 3 X 1.5V AAA * Dimension: 8.86 X 2.36 X 1.18 in * Weight: Approx 0.7 lb ( includes battery) * Audible continuity and Diodes * It comes with a carrying case * Confirmed with IEC1010 CAT III * This meter is built for rough use and with accurate readings. Compare with MS2138R, this meter is NOT a true RMS meter (please look at our rules and privacy policy) |
